Autoradio per 2Din Universal Unit Nissan Car GPS WiFi 4G TPMS DVR DAB+ Wireless Apple CarPlay DSP Amplif

Key Features:

- Android 11.0 OS, Quad Core, 2GB RAM and 32GB ROM, 2 USB up to 2*128GB extended Storage.
- Built-in DSP Amplifier System, 36-Band EQ Selections, which bring the perfect sound effect in your car.
- Built-in Wireless Apple CarPlay and Wired & Wireless Android Auto module, you don't need to use another adapter, just connect your iPhone to this unit via Bluetooth to use the CarPlay function, or connect your Android phone to this unit via USB / Bluetooth to use the Android Auto function.
- Built-in Bluetooth module, which supports hands-free function with A2DP Audio Streaming
- Built-in GPS Module, which supports offline GPS Navigation, GPS ready to use.
- Built-in WiFi Module for Internet, you can Link mobile hotspot to use Google online Navigation
- Built-in Android Multimedia Player, can play Music/Video/Photo from local Disc or USB.
- Built-in USB, Radio, RDS, WiFi, Clock, Calendar Calculator.
- Support DAB+, DVB-T/T2, TPMS, OBD2, DVR, Camera, AVIN, 3G, 4G etc. extended functions.
- Support steering wheel control, easier and safer to adjust volume, answer calls and switch the songs while driving.
- Built-in 7 Theme UI-Style, our unique Design, you can choose your favorite style. Support DIY wallpaper.
- Support Split Screen, you can run two apps side by side.

Compatible Models & Years:

ISO 2Din Universal Unit, also it can be used as special unit for many NISSAN Cars

Important Note:
For NISSAN Cars, you may need buy special Nissan Power Cable from us, please refer to the wiring diagram mentioned later.


��

  General
- Power Supply: DC 12V (allowance range: 10.8-14.5V)
- Max. Current: 10A
- Screen Size: 7 inch
- Install Size: 2Din Size, 180mm*100mm*36mm
- Package Size: 220mm*190mm*140mm
- Shipping Weight: 2.0kg

��

  System
- Operation System: Google Android 11.0
- CPU: 1.3GHz Cortex A7
- RAM: 2GB
- Internal Memory: 32GB
- Extended Card/USB: Support USB stick up to 128GB

��

  Display
- Screen Type: Multi-touch screen
- Multi-windows view: Yes, support Split Screen, you can run two apps side by side
- Resolution: 1024*600
- Capacitive or Resistance Screen: Capacitive
- Built-in Clock and Calendar: Yes, show real time and can use network-provided time
- Main Menu Status Icon display: Music/Radio/BT-Stereo Player and Clock/Date/Week
- Change Wallpapers: built-in 7 wallpapers, support User's wallpaper

��

  Internet
- WiFi Internet: Built-in WiFi Module, support 802.11b/g/n, support WiFi Hotspot
- 3G/4G Internet: USB 3G/4G Dongle not included, just contact us to buy it together
- Explorer: Opera, UCWeb, SkyFile, Dolphin and more explorer for your selection
- Online Entertainment: Online Video, TV, Movie, Music, Radio, Video Chat
- Online Navigation: Online Google Maps Navigating
- Online Games: Yes, online play or you can download it from play store
- Online Music: Yes, use apps like Spotify, Amazon Music, Google Music, Apple Music, Deezer downloaded from PlayStore.
- Online Communication: keep connected through WhatsApp, WeChat, Twitter, Facebook, Gtalk, Gmail...
- Read and edit Office Software: Yes, support Word, Excel, Powerpoint, PDF, TXT

��

  Audio
- Format: MP3, WMA, MP2, OGG, AAC, MA4, FLAC, APE, WAV etc. Could play via song list
- Record: MP3, WMA
- Other: LRC synchronized display; ID3 search; Search by files; Album Picture; User-defined audio effect
- Audio IC: Top Global Cirrus IC, independent audio decoding
- SNR: Noise rations:=90dB

��

  Video
- Format: Support AVI (H.264, DIVX, XVID), rm, rmvb, MKV (H.264, DIVX, XVID). WMA, MOV, MP4 (H.264, MPEG,
  DIVX, XVID). DAT (VCD format). VOB (DVD format). PMP, MPEG, MPG. FLV (H.263, H.264). ASF, TS, TP, 3GP,
  MPG ect. =30 formats, Playing internet video directly (while downloading)
- Play: Up to 1920*1080 Pixels, 30Mb. Fluent play without light spot
- Video Output: Common Video Output

��

  GPS
- Operation System: Android 11.0
- Support Maps: IGO, Sygic, Waze maps for Android 11.0
- Support offline navigation: Yes, Ready to use.
- Dual Zone: Yes, navigating while music playing
- Online Navi: Yes, support online navigating such as google maps

��

  Bluetooth
- Hands Free: Yes
- A2DP (Bluetooth Stereo Music): Yes, can play stereo music through Bluetooth
- PB-Download: Yes, can download phonebook from mobile to this unit
- PB-Search: Yes, can use the first letter to search contact member in PB-Listings
- Calling Records: Yes, Dialed Call, Received Call, Missed Call
- Built-in Microphone: Yes, on the front panel

��

  Radio
- Main Chips: NXP6856
- AM Frequency Range: 522-1620KHz
- AM Increment: 9KHz(EU)/10KHz(US)
- FM Tuning Range: 87.5-108MHz
- FM Increment: 0.05MHz(EU)/0.1MHz(US)
- RDS: On/Off
- Preset Stations: Yes

��

  USB
- Position: 2 USB On the Back
- Function: Can be connected with U-Disc, 3G/4G Dongle, CarPlay Dongle, TPMS-Device, DVR-Camera, DAB+ Box, Smartphone etc.
- Capacity: 128GB
- Play MP5 Videos: Yes, can play RMVB Videos up to 1080P

��

  Android Auto
- Built-in Android Auto: Yes, just connect your smartphone to this unit with USB/Bluetooth to use this function
- Connection: USB/Bluetooth, support wired & wireless Android Auto
- Support Device: Android Smartphone with Android 5.0 and above
- Control the connected Android Phone on head unit: Yes

  CarPlay
- Built-in CarPlay: Yes, just connect your smartphone to this unit with Bluetooth to use this function
- Connection: Bluetooth, support wireless Apple CarPlay
- Support Device: iPhone iOS 7.1 and above
- Unit's Screen Control Phone: No, but you can download CarPlay supported function APK to use and control

��

  Car DVR
- Built-in DVR App: Yes, just connect a USB DVR Camera to use this function
- Connection Port: USB
- Storing Position: TF Card in Camera
- Touch Control DVR-Camera on unit: Yes
- DVR-Camera incl.: No, you can contact us to buy it together

��

  TPMS-IN
- Built-in TPMS App: Yes, just connect a TPMS Module to use this function
- Connection Port: USB
- Power Supply to TPMS Module directly: Yes
- Touch Control TPMS Module on unit: Yes
- TPMS Module incl.: No, you can contact us to buy it together

��

  DAB(+)-IN
- Built-in DAB Player App: Yes, just connect a DAB+ Box to use this function
- Connection Port: USB
- Power Supply to DAB+ Box directly: Yes
- Touch Control DAB+ Box on unit: Yes
- DAB+ Box incl.: No, you can contact us to buy it together

��

  AV-IN
- Built-in AV-IN App: Yes, Support external Audio & Video Input
- Connection Port: RCA
- Support DTV-IN: Yes, you can connect with a Digital TV Box (DVB-T/T2, ATSC, ISDB) to use

��

  Additional
- Textbook: Could change font, font color, background color, bookmark, reading E-book while listening music
- Photo Viewer: Support JPS, BMP, PNG, GIF etc. format. play by revolve, Powerpoint Support 4096*4096 Pixels
- APK Installer: Support Android Package installer
- Support Torque Pro(OBD2 &Car): Yes, you can connect a Bluetooth OBD2 Scanner Tool to use this function
- Support steering wheel control
- Built-in DSP Amplifier System, 36-Band EQ Selections, which bring the perfect sound effect in your car.
- Built-in 7 Theme UI-Style, our unique Design, you can choose your favorite style.
- Smart UI Design, support DIY wallpaper and panel light colors.

��

  Input
- AUX Video In: One
- Rear-View Camera Video In: One
- AUX Audio In: R/L
- TPMS Box In: One
- DAB+ Box In: One
- Car DVR In: One

��

  Output
- Video Out: One
- Audio Out: R/L
- Surround Stereo Out: 4*45w
- Subwoofer Out: One

��

  Accessories
- 1*User's Manual in English
- 1*RCA AV Connecting Cable
- 1*Camera input cable
- 1*Power Cable with ISO Connector
- 2*Rear USB Adapter Cables
- 1*GPS Antenna
- 1*Install Frame
- 1*Install Fittings
