ES580 18mm Mini 170 Viewing Color CCD Car Reversing Camera Guide Line

KEY FEATURES:
- The newest Mini Design, it has only 18mm body size, perhaps it is the smallest camera in the world.
- Built-in SONY CXD3142R CCD Chips outputs digital signals which has better clarity, color contrasting and sharpness than the CMD camera.
- IP67/IP68 Water-proof-Rating, 8 hours in water tested, can achieve 100% waterproof
- 170 degree wide angle viewing helps avoid accidents & injuries
- Easy to install, 6m Length RCA Video Cable and 1m length power cable
- Built-in reversing guide line, it can help you to estimate the distance while reversing.


Spefication:
- Image Sensor: 1/4 – inch Color CCD
- Video System: NTSC
- Effective Pixels: 818*622
- Resolution: 480 TV Lines
- Sensor Area: 5.78mm*4.19mm
- Scanning System: 2:1 Interface
- Lens: 1.7mm
- Sync System: Internal
- Electronic shutter: 1/60 1/15,000 seconds
- S/N Ratio: More than 48db
- Mini Illumination: 0.3Lux/F1.2
- Video Output: 1.0Vp-p, 75Ohm
- RCA Video Cable: 6M
- Current Consumption: 120Ma
- Power Supply: DC 12V
- Operating Temperature: -10°~+50°Rh95% MAX
- Storage Temperature: -30°~+60°Rh95% MAX
- Automatic White Balance: Yes
- AGC (Automatic Gain Control) : Yes
- BLC (Back Light Control) : Yes
- Net Weight: App. 60g
- Gross Weight: 200g


Package Content:
1 * Mini CCD Camera
1 * 6M Video Cable
1 * 1M Power Cable
1 * Screws
1* User's Manual in English
